EK-Quantum AM5 - Page 8

- 8 -
STEP 3
Insert all four (4) saved Springs inside the Frame.
STEP 3
STEP 4
STEP 4
Loosely insert all four (4) saved Screws before proceeding to tighten them
(using Allen Key 2.5 mm) two revolutions at once in a cross pattern. Stop
when every Screw is flush with its hole inside the Frame!
MOUNTING
SCREW
MOUNTING
SPRING
