EK Loop Vertical GPU Holder EVO Gen4 Riser - Step 11: GPU Mounting to Holder; Step 12: GPU Cable Connection

- 15 -
STEP 11
Carefully mount the GPU onto the GPU Holder with the two UNC
6-32x1/4 screws. Pay special attention not to damage the GPU.
STEP 12
Finally, connect the GPU cables (as instructed by the GPU manufacturer)
to complete the installation.
STEP 11
UNC 6-32x1/4” SCREW
