EK Vector TRIO RTX 3080 - Technical Specifications and Product Parts

- 6 -
TECHNICAL SPECIFICATIONS AND PRODUCT PARTS
Technical Specification:
Dimensions (L x H x W): 308 x 153 x 38 mm
D-RGB (Addressable RGB) Cable Length: 500 mm
D-RGB LED Count: 5 (Plexi Version)
D-RGB Connector: Standard 3-Pin (+5V, Data, Blocked, Ground)
Position EAN Description Quantity
1
104230 Alu cover (Ni)
1
104231 Alu cover (Bl. elox)
2 104233 Coldplate (Ni) 1
3
104236 Top plate (Plexi)
1
104237 Top plate (Acetal)
4 104238 Standout (only for plexi version) 1
5
104235 Plexi Terminal
1
104234
Acetal Terminal
6 4720 Terminal metal blank 1
7 5155 O-ring 15x1 4
8 100006 M4 x 27 DIN7984 Screw 6
9 9013 M4 x 8 DIN7984 Screw 12
10 100663 EK RGB Badge 1
11 104316 Main O-ring 1
12 100199
LED D-RGB Strip (only for plexi version) 1
13 9058 M2.5 x 6 AX1 Screw 3
14 102639 Plug G1/4 1
14
8
12
6
13
4
2
1
11
10
9
7
3
5
