EK Vertical GPU Holder EVO - STEP 2: Apply Protective Foam; STEP 3: Attach PCIE Riser Cable

- 8 -
STEP 2
Stick two (2) protective adhesive foams, as indicated in the diagram.
The »2 mm protective foam« should be enough for the protection of
your GPU during installation.
STEP 2
STEP 3
Attach the PCIE riser cable to the bracket’s assembly with three (3)
M2.5 x 4 Phillips pan head screws.
STEP 3
M2.5x4 SCREW
PROTECTIVE FOAM
RISER CABLE
