- 3 -
TABLE OF CONTENTS
BOX CONTENTS 4
REQUIRED TOOLS 5
WATER BLOCK DIMENSIONS 5
WATER BLOCK SPECIFICATIONS AND MAIN PARTS 6
PREPARING THE GRAPHICS CARD 7
REMOVING THE STOCK COOLER 7
REMOVING THE I/O COVER 7
REMOVING THE STOCK BACKPLATE AND COOLER FRAME 8
CLEANING THE PCB 8
CUTTING AND PLACING THERMAL PADS 9
APPLYING THERMAL COMPOUND 10
INSTALLING THE WATER BLOCK 11
PLACING THE BLOCK ON THE GRAPHICS CARD 11
ATTACHING THE BLOCK TO THE GRAPHICS CARD 11
ATTACHING THE I/O COVER 12
CHECKING FOR CONTACT 12
INSERTING THE GRAPHICS CARD INTO THE CHASSIS 13
INSTALLATION OF FITTINGS AND TUBING 13
CONNECTING THE D-RGB LED STRIP 14
TESTING THE LOOP 14
SUPPORT AND SERVICE 15
SOCIAL MEDIA 15
