ekwb EK-Quantum Volume FLT Series - Mount Reservoir Only to Radiator; Mount Reservoir to Case with Brackets

- 8 -
3c.
Alternatively the shorter 5mm long screws from the radiator may be
used to mount only the reservoir.
M4 x 10 DIN
7984 Screw
M4 Nut
3d.
Lastly the supplied M4 nuts, washers and M4x10 screws may be
used to secure the reservoir to a case with the mounts. This is useful
when there is no clearance behind for the pump or to prevent all
airflow being blocked
UNC 6-32 x 5
ISO 7380 Screw
Radiator
FLT M o unt
M4 metal Washer
