ekwb EK-Quantum Volume FLT Series - Installing EK-Quantum Volume; Kinetic FLT Reservoir into the Case; Mount Reservoir to Fan; Mount to Radiator and Fans

- 7 -
3a.
Included M4 nuts, washers and M4x10 screws can be used to mount
the flat reservoir to a fan.
INSTALLING EK-QUANTUM VOLUME / KINETICFLT RESERVOIR IN TO THE CASE
120 mm Fan
UNC 6-32 x 30
ISO 7380 Screw
3b.
Using 30mm long screws supplied with your radiator the reservoir
can be mounted onto the radiator and 25mm thick fans together.
M4 x 10 DIN
7984 Screw
M4 Nut
M4 metal Washer
