ekwb EK-Quantum Volume FLT Series User Manual

- 9 -
EK-Quantum Kinetic FLT has two inlet and two outlet ports, one of each
must be used! All 4 unused ports should be blocked using G1/4 plugs.
ATTACHING THE FITTINGS
EK-Quantum Volume FLT has two ports which can be used as inlet or
outlet, the chosen outlet should connect directly to your pump! The
reservoir should be positioned above the pump to ensure it does not
run without coolant. Both unused ports should be blocked using
G1/4 plugs.
FILL
DRAIN
OUTLET
INTLET
OUTLET
FILL
DRAIN
INTLET / OUTLET
