12
IR Remote/Front Panel Control
IR REMOTE/FRONT PANEL CONTROLS
The DS-A101-G can be controlled via the included IR Remote, front panel controls or DS-
A101-G app. The front panel and remote would typically be used for amp control. The
apphasuniquefeaturesthatcanbeusedfornetuningampperformancebasedupon
thespecicsources,speakersandroomconditions.ThissectioncoversfrontpanelandIR
Remote control. See section: DSA101-G App for information on the use of the app for setup
andnetuning.
ON/OFF
On the IR Remote, Press the button to turn the amp ON. Press again to turn the amp OFF.
On the front panel, Press the Power button to turn the amp ON. Press again to turn the amp
OFF. When the amp is turned ON, the front panel display will show the ELAC logo followed by
the volume level, current source. If the source is outputting a Dolby Digital signal, the Dolby
Audio™ Logo will appear. When the amp is turned OFF the display will turn off.
VOLUME/MUTE
On the IR Remote, Press the button to increase volume. Press the button to
decrease volume. Press the button to mute audio output. Press the button again to
un-mute audio output. On the front panel, turn the Volume knob clockwise (right) to increase
volume. Turn the Volume knob counter-clockwise (left) to decrease volume. There is no front
panel mute control.
When adjusting volume, the volume level will appear in the front panel display.
NOTE: If a subwoofer is connected, the volume/mute controls will affect speaker and sub
volume/mute. If headphones are connected, output to the speakers/sub will be cut and the
volume/mute controls will affect headphone volume/mute.
SOURCE SELECT
On the IR Remote, press the Ana 1, Ana 2, Opt, , Coax or USB buttons to select a
specicsource.Onthefrontpanel,taptheSourcebuttontochangesourceselectionone
at a time. Press and Hold to scroll through available sources to the desired selection.
NOTE: For a Bluetooth source, see section: Bluetooth for additional information.
