Elan STROBE-1000-LED-RGB+W User Manual

14
DMX Values In-Depth (8-Channel Mode)
DMX Values In-Depth (7-Channel Mode)
DMX Values In-Depth (4-Channel Mode)
Ch. Value Function
1 000 <--> 255 Master Dimmer (0-100%)
2 000 <--> 255 Red segment Intensity (0-100%)
3 000 <--> 255 Green segment Intensity (0-100%)
4 000 <--> 255 Blue segment Intensity (0-100%)
5 000 <--> 255 White segment Intensity(0-100%)
6 000 <--> 255 Flash duration (0-full on)
7 000 <--> 255 Strobe rate (0-30Hz)
8
000 <--> 005
Built-In Programs
No function
006 <--> 042 Ramp up effect (slow <--> fast)
043 <--> 085 Ramp down effect (slow <--> fast)
086 <--> 128
Ramp up-down effect (slow <-->
fast)
129 <--> 171 Random effect (slow <--> fast)
172 <--> 214 Lightning effect (slow <--> fast)
215 <--> 255 Spike effect
Ch. Value Function
1 000 <--> 255 Master Dimmer (0-100%)
2 000 <--> 255 Red segment Intensity (0-100%)
3 000 <--> 255 Green segment Intensity (0-100%)
4 000 <--> 255 Blue segment Intensity (0-100%)
5 000 <--> 255 White segment Intensity(0-100%)
6 000 <--> 255 Flash duration (0-full on)
7 000 <--> 255 Strobe rate (0-30Hz)
Ch. Value Function
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Flash Duration (0% <--> 100%)
3 000 <--> 255 Strobe Rate (0-30Hz)
4
000 <--> 005
Built-In Programs
No function
006 <--> 042 Ramp up effect (slow <--> fast)
043 <--> 085
Ramp down effect (slow <-->
fast)
086 <--> 128
Ramp up-down effect (slow <-->
fast)
129 <--> 171 Random effect (slow <--> fast)
172 <--> 214 Lightning effect (slow <--> fast)
215 <--> 255 Spike effect
