Elan STROBE-1000-LED-RGB+W User Manual

15
DMX Values In-Depth (7-Channel Mode)
DMX Values In-Depth (1-Channel Mode)
DMX Values In-Depth (4-Channel Pixel Mode)
Ch. Value Function
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Flash Duration (0% <--> 100%)
3 000 <--> 255 Strobe Rate (0-30Hz)
Ch. Value Function
1 000 <--> 255 Dimmer (0% <--> 100%)
Ch. Value Function
1
000 <--> 021 No Function
022 <--> 255 Red/Segment Intensity (0% <--> 100%)
2
000 <--> 021 No Function
022 <--> 255 Green/Segment Intensity (0% <--> 100%)
3
000 <--> 021 No Function
022 <--> 255 Blue/Segment Intensity (0% <--> 100%)
4
000 <--> 021 No Function
022 <--> 255 White/Segment Intensity (0% <--> 100%)
DMX Values In-Depth (8-Channel Pixel Mode)
Ch. Value Function
1
000 <--> 021 No Function
022 <--> 255 Red/Segment 1 Intensity (0% <--> 100%)
2
000 <--> 021 No Function
022 <--> 255 Green/Segment 1 Intensity (0% <--> 100%)
3
000 <--> 021 No Function
022 <--> 255 Blue/Segment 1 Intensity (0% <--> 100%)
4
000 <--> 021 No Function
022 <--> 255 White/Segment 1 Intensity (0% <--> 100%)
5
000 <--> 021 No Function
022 <--> 255 Red/Segment 2 Intensity (0% <--> 100%)
6
000 <--> 021 No Function
022 <--> 255 Green/Segment 2 Intensity (0% <--> 100%)
7
000 <--> 021 No Function
022 <--> 255 Blue/Segment 2 Intensity (0% <--> 100%)
8
000 <--> 021 No Function
022 <--> 255 White/Segment 2 Intensity (0% <--> 100%)
