12.3 Maintenance menu
Maintenance & Commissioning Menu
ID line Description Range Factory Default Comments
SYSTEM PRES Current System Pressure
0-6.0bar ** Actual value - Review only
COLDFILLPRES
Cold Fill Pressure (pump cut-out) P2
0.7-3.4bar 1.8bar
Can be altered
MAKE-UP V0
Volume of Water Introduced
0-9999 L *** Actual value - Review only
MAKE-UP ALARM
Water Introduction Alarm
00-99L 99
Can be altered
and can
be disabled by setting to 00.
Actual volume=XX*10 L
MAKE-UP V2
Volume of Water Introduced
(since last rest)
0-999.9 L ***
Actual value - Reset
PUMP OPS
Number of pump cycles
0-9999 ***
Actual value - Reset
PUMP1 HRS
Hours operation of pump1
0-99.59 **:**
Actual value - Reset
PUMP2 HRS
Hours operation of pump2
0-99.59 **:**
Actual value - Reset
CUT IN PRES Pump cut-in Pressure P1 0.5-3.2bar 1.4bar Recommended value - P1=P2-0.4
L PRES ALARM Low Pressure Alarm 0-3.0bar 1.2bar
Recommended value -
Safety valve setting +0.3 bar
H PRES ALARM High Pressure Alarm 0.9-6.2bar 3.6bar
Recommended value-
Safety valve setting -0.3 bar
PUMP MIN RUN Pump minimum run time 1-9.9 secs 1.0sec Minimum operating time for pump
PUMP MAX RUN Pump maximum run time 01-99 min 99min Maximum operating time for pump
PUMP DELAY Pump minimum cycle time 0-99 min 00min
Minimum off time for pump
to stop hunting ON/OFF
PUMP KICK Pump duty cycle time 0-99 days 30days
Number of days pump is
idle then operated for 1 sec
PUMP Pump selection
PUMP1
PUMP2
ALTERNATE
ALTERNATE
Pump 1 only
Pump 2 only
Auto rotation
PASSCODE Password ON / OFF OFF Pass code =21
PUMP TIMEOUT Pump failure time 1-99 min 03min
Self diagnostic check that the
pressure is increasing by 0.005 bar
within the selected tim
FILL FUNCTION Automatic filling function - -
Press
on this menu to
operate function
Detailed below are the parameters which should only be accessed by a competent person.
Note: These Settings will affect the operational function of
the appliance, hence, alterations should only be undertaken
by a competent person.
Once the settings are complete, press and
& Program
Buttons simultaneously for 5 seconds and the screen will
revert to USER MENU OFF.
* The pump fitted within this unit
is capable of a maximum Cold Fill Pressure of 3.0Bar
