02/2009 - Art. Nr. 4200 1015 7800A

VECTRON ECO 1.34

VECTRON ECO 1.35

VECTRON ECO 1.50

VECTRON ECO 1.52

VECTRON ECO 1.75

Bedieningshandleiding

Voor de gespecialiseerde vakman

Aangeblazen oliebrander Low NOx ..... 2-13

nl

Operating instructions

For authorised specialist

Low NOx

forced-draught fuel-oil burner

14-25

en

de, fr, it................................. 4200 1015 7700

............................................. 4200 1015 7900

Table of Contents

Questions and Answers:

A
Abigail StoutAug 13, 2025
What to do if the flame goes out during operation in my Elco Burner?
- C
  Crystal PeckAug 13, 2025
  If your Elco Burner's flame goes out during operation, first, ensure that the oil level in the tank is adequate and that all valves are open. Then, inspect the oil pressure, pump operation, coupling, filter, and solenoid valve. Verify the ignition circuit and electrode adjustment, cleaning or replacing electrodes if necessary. Also, clean or replace the flame monitor. Replace any faulty components, such as ignition electrodes, cables, the ignition transformer, nozzle, pump, solenoid valve, or the automatic combustion control unit, as needed.
E
Elizabeth RodriguezAug 16, 2025
Why my elco VECTRON ECO 1.35 Burner does not start but there is no malfunction indicated?
- A
  ashley97Aug 16, 2025
  If your Elco Burner doesn't start and the automatic combustion control unit shows no malfunction, it could be due to a drop in supply voltage or a power failure. Investigate and fix the cause of the voltage drop or power failure. If the issue persists, the control unit may be malfunctioning and should be replaced.
C
Christopher MillerAug 20, 2025
What to do if my elco VECTRON ECO 1.35 starts and then shuts down immediately?
- R
  Robert MillsAug 20, 2025
  If your Elco Burner starts briefly when switched on and then shuts down, the control unit may have been manually locked. Try resetting the control unit to resolve this issue.
P
Paula JeffersonAug 25, 2025
Why does my elco VECTRON ECO 1.35 start and then shut down after preventilation?
- S
  scastroAug 25, 2025
  If your Elco Burner starts and then shuts down after pre-ventilation, it might be due to a parasitic flame during the pre-ventilation or pre-ignition phase. Inspect the ignition sparks, adjusting or replacing the electrode as necessary. Also, check and potentially replace the fuel-oil solenoid valve.
A
alicia62Aug 28, 2025
How to fix no heat request on elco VECTRON ECO 1.35?
- C
  Christopher RodriguezAug 28, 2025
  If there is no heat request in your Elco Burner, the thermostats might be defective or incorrectly adjusted. Try adjusting the thermostats, and if the problem continues, replace them.
B
benjamin14Aug 31, 2025
What to do if my elco Burner does not start but shows no malfunction?
- J
  Jessica HenrySep 1, 2025
  If your elco Burner doesn't start and the automatic combustion control unit shows no malfunction, it could be due to a drop in supply voltage or a power failure. You should check the cause of the voltage drop or power failure. Another possible cause is a control unit malfunction, in which case you should replace the control unit.
B
Brittany CarrollSep 4, 2025
Why does elco Burner start and then shut down after preventilation?
- D
  Donna WrightSep 4, 2025
  If the elco Burner starts and then shuts down after preventilation, it could be due to a parasitic flame during the preventilation/pre-ignition phase. You should check the ignition sparks and adjust or replace the electrode. Also, check or replace the fuel-oil solenoid valve.
D
Deborah KnoxSep 8, 2025
How to fix elco Burner with no heat request?
- M
  Mark WilsonSep 8, 2025
  If there is no heat request for your elco Burner, the thermostats might be defective or incorrectly adjusted. Adjust the thermostats or replace them if necessary.

elco VECTRON ECO 1.35 Specifications

General

Brand	elco
Model	VECTRON ECO 1.35
Category	Burner
Language	English

Summary

Operating Instructions

Product Identification

Identifies the VECTRON ECO Low NOx forced-draught fuel-oil burner model.

Overview and Compliance

Declaration of Conformity

States compliance with European directives and standards for the burner.

Important Notes

Provides crucial preliminary information and warnings for installation and use.

Burner Description

Technical Details and Features

Details the single-stage, fully automatic monoblock-type burner and its low-polluting design.

Functionality

Heating and Operating Functions

Explains the burner's heating sequence, operating cycle, and controlled shutdown process.

Safety Functions

Describes safety shutdown conditions and procedures, including parasitic flame monitoring.

Automatic Combustion Control Unit

Details the operation, locking, and unlocking of the TCH 1xx automatic combustion control unit.

Connection Socket Allocation

Provides a chart mapping terminal designations to connector numbers for electrical connections.

Assembly and Installation

Burner Assembly and Installed Depth

Guides on assembling the burner, adjusting installed depth, and securing it to the boiler.

Flame Tube Installation

Instructions for installing the flame tube, including special considerations for different models.

Electrical and Oil Connections

Details on making electrical connections and plumbing the oil supply and return lines.

Checks Before Commissioning

Lists essential checks to perform before the initial start-up of the burner system.

Start-up Procedures

Adjustment Data and Air Regulation

Provides tables for burner output settings and instructions for air intake adjustment.

Oil Pressure Regulation and Operating Check

Guides on adjusting oil pressure and performing operational checks, including flame monitoring.

Service and Maintenance

Maintenance Procedures

Outlines routine maintenance tasks, including exhaust gas checks and burner servicing positions.

Troubleshooting Common Faults

Diagnoses common malfunctions, their causes, and recommended remedies for the burner.

Maintenance Indicators

Explains how to access and interpret maintenance frequency and fuel oil stock indicators.
