Elcomed settings – Documentation
Documentation is only possible at a preselected speed ≤50 rpm and only with transmission settings 975, WS-75 and WI-75.
Speed, torque and coolant can be changed during documentation.
Recording starts after a minimum torque of 1 Ncm is reached and ends 10 seconds after the motor is switched off.
If the motor is restarted within 10 seconds, recording will continue even if the minimum torque of 1 Ncm
has not yet been reached.
A picture file (bmp) and a text file (csv) are saved on the USB flash drive. The text file can be imported into
Microsoft®* Office Excel®** for further processing. The csv file can be opened either by double-clicking or
by right-clicking on the file and selecting »Open with...«.
> bmp file (torque progression, date, time, display screenshot)
> csv file (torque data)
Do not use the saved bmp file and the csv file for diagnostic purposes.
Make absolutely sure that the USB flash drive is plugged into your computer correctly.
