Elcometer 108 User Guide

www.elcometer.com
en-14
R
11 WARRANTY STATEMENT
Elcometer 108
Analogue
Digital
Standard Flat
Dolly
2
Area: 284mm (0.44 sq. inch)
Inside Diameter: 3.7mm (0.15")
Outside Diameter: 19.4mm (0.76")
Scale Range
0 - 25MPa
(0 - 3600psi)
0 - 25MPa
(0 - 3600psi)
Operating Range
(Certified)
2 - 18MPa
(290 - 2600psi)
2 - 18MPa
(290 - 2600psi)
Scale Resolution
1MPa (100psi)
0.1MPa (1psi)
Accuracy
1MPa (150psi)
±3% or 0.4MPa
d
(60psi)
e
Power Supply
-
2 x AA alkaline
dry batteries
Tester Length
520mm (20")
Tester Weight
1.4kg (3lb)
Kit Dimensions
497 x 411 x 140mm (19.6 x 16.2 x 5.5")
Kit Weight
4.9kg (10.8lb)
Can be used in accordance with:
ASTM D 4541, ISO 16276-1, NF T30-606
Note: The Elcometer 108 Hydraulic Adhesion Tester is a Type III adhesion tester as
defined by ASTM D4541.
d
Whichever is the greater.
e
Rechargeable batteries can be used.
12 TECHNICAL SPECIFICATION
The Elcometer 108 is supplied with a one year warranty against
manufacturing defects, excluding contamination and wear.
