Elcometer 415 User Manual

Range
0 - 1000µm (0 - 40mils)
Accuracy
b
±1-3% or ±2.5μm (±0.1mil)
Resolution
0.1μm: 0-100μm; 1μm: 100-1000μm
(0.01mil: 0-5mils; 0.1mil: 5-40mils)
Minimum Substrate
Thickness
Steel:
Aluminium:
100µm (4mils) - FNF gauges only
300µm (12mils)
Measurement Speed
Up to 60 readings per minute
Operating
Temperature
-10 to 50°C (14 to 122°F)
Relative Humidity
0 to 95%
Power Supply
2 x AA Batteries or via USB Cable
(rechargeable batteries can also be used)
Battery Life
C
Alkaline: Approximately 16 hours
Lithium: Approximately 24 hours
Gauge Dimensions
14.1 x 7.30 x 3.70cm
(5.55 x 2.87 x 1.46")
Gauge Weight
(including batteries)
156g (5.5oz)
Can be used in accordance with:
AS2331.1.4, AS/NZS 1580.108.1, ASTM B 499, ASTM D 1186,
ASTM D 1400, ASTM D 7091, ASTM E 376, BS 3900-C5-6A,
BS 3900-C5-6B, BS 5411-11, BS 5411-3, BS 5599, DIN 50981,
DIN 50984, ECCA T1, EN 13523-1, ISO 2178, ISO 2360, ISO 2808-12,
ISO 2808-6A, ISO 2808-6B, ISO 2808-7C, ISO 2808-7D,
JIS K 5600-1-7, NF T30-124
b
When subject to a 2-point calibration: ±1% when calibrated close to the required thickness, ±3% across
the range.
C
Rechargeable batteries may differ.
12 TECHNICAL SPECIFICATION
www.elcometer.com
en-10
