14-42
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.42 Outdoor Unit ONG3 17 RC
No. Part No Description Quantity
1 433218
Front panel A 1
2 433221
Air Inlet Ring-420 1
3 433223
Painting Insulation Plate 1
4 4519251
Fan 1
5 4520171
Fan Motor 1
6 4527203
Motor support 1
7 464600001
Base Painting Assy. 1
8 4527202
Partition plate 1
9 455000506
Compressor Capa.30uF 1
10 453013500
Painting Electric Plate 1
11 4524176
Liquid Valve 1
12 4524595
Gas Valve 1
13 455000001
Capacitor 2uF 1
14 4514588
5 Poles Terminal block 1
15 204107
Cable clip Nylon 1
16 236179
2 Poles Terminal block 1
17 4516637
Out sensor Black 1
18 463600000
Capillary Assy. 1
19 469270002
Compresssor Jacket 1
20 463230014
2-Way Strainer 1
21 4510677
Nut With Flange M8 3
22 4519987
Wire assy 1
23 460000000
Compressor Assy/PA200X2CS-4KT1 1
24 433229
Valve Cover 1
25 433234
Clamp 1
26 4519606
Right Side Plate 1
27 461600001
4-Way Valve Assy. 1
28 4518952
4-Way Valve SHF-7H for R410A 1
29 4520071
4-Way Valve coil for R410a 1
30 433228
Back Side Net 1
31 433216
Bridge 1
32 462300003
Condenser Soldering Assy. 1
33 4519614
Painting Top Cover 1
34 4519300
Fan Nut M5 Left Rotation 1
35 433225
Right Handle 1
36 4519607
Left side panel 1
37 470120001
Rubber Cushion /Base Plate 4
38 453121300
Install Accessory 1
