14-43
EXPLODED VIEWS AND SPARE PARTS LISTS
SM ALPHA 1-E.3 GB
14.43 Outdoor Unit ONG3-17 RC R410A A2
No. Item Code Item Description Quantity
1 433218 Front Panel A 1
2 433221 Air Inlet Ring-420 1
3 464860054 Painting Insulation Plate Assy/ONG 1
4 4519251 Axial Fan OD=400 1
5 4520171R Fan Motor (910rpm) 1
6 4527203 Motor Support 1
7 464600001 Base Plate Painting Assy. 1
8 4527202 Partition Plate 1
9 455000506 Compressor Capacitor With Screw 1
10 453012700 Electric Panel 1
11 4524176 1/4 Liqiud Valve(R410A) 1
12 4524595 1/2 Gas Valve for ONG R410A 1
13 455000001 single patch Capacitor for fan 1
14 4514588 5 Poles terminal block 1
15 204107 Cable clip Nylon 1
16 236179 2 Poles terminal block 1
17 4516637 Out sensor Black 1
18 463600000 Capillary Assy 1
19 469270002 Insulation Rub+Felt/Compress 1
20 463230014 Way Strainer 1
21 4510677 Nut With Flange M8 -D=24 3
22 4519987 Wire assy 1
23 460000000 Compressor Assy./ GMCC PA200X 1
24 433229 Valve Cover 1
26 4519606 Right side panel (painting plate) 1
27 461600001 4Way Valve Assy. 1
28 4518952 4-W valve SHF-7H for R410A 1
29 4520071 4-W valve coil for R410A 1
30 433228 Back Side Net 1
31 4526298 Bridge 1
32 462300003 Condenser Assy. 1
33 4519614 Painting Top Cover 1
34 4519300 Nut M5 L 1
35 433225 Handle 1
36 4519607 Left Side Panel Painting Plate 1
37 470120001 Rubber Cushion /Base Plate 4
38 453121300 Install. Accessory 1
