PERFORMANCE DATA & PRESSURE CURVES
SM ALPHA 1-E.3 GB
5.3 Alpha7 DF / GCN7 RC R410A A2
5.3.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
Entering Air DB
OD Coil(
o
C)
Data
Entering Air WB/DB ID Coil(
o
C)
15/21 17/24 19/27 21/29 23/32
15
TC 2.40 2.49 2.55 2.61 2.65
SC 1.67 1.74 1.81 1.85 1.89
PI 0.44 0.44 0.44 0.44 0.44
20
TC 2.33 2.45 2.53 2.59 2.64
SC 1.64 1.73 1.80 1.85 1.88
PI 0.48 0.48 0.48 0.48 0.48
25
TC 2.20 2.38 2.50 2.57 2.64
SC 1.59 1.69 1.78 1.84 1.87
PI 0.52 0.52 0.52 0.53 0.53
30
TC 2.06 2.24 2.42 2.51 2.58
SC 1.54 1.64 1.75 1.80 1.83
PI 0.56 0.56 0.57 0.57 0.58
35
TC 1.90 2.07 2.28 2.39 2.51
SC 1.47 1.57 1.71 1.75 1.79
PI 0.60 0.61 0.62 0.62 0.63
40
TC 1.73 1.89 2.06 2.25 2.37
SC 1.38 1.49 1.61 1.66 1.70
PI 0.65 0.66 0.67 0.68 0.68
46
TC 1.50 1.64 1.81 2.00 2.15
SC 1.28 1.37 1.47 1.52 1.56
PI 0.71 0.72 0.73 0.74 0.75
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, an A.S.K Kit is required.
