5-6
PERFORMANCE DATA & PRESSURE CURVES
SM ALPHA 1-E.3 GB
5.3.2 Heating
ENTERING AIR DB ID COIL(
O
C)
15 20 25
ENTERING WB
OD COIL(
o
C)
TH Pl TH Pl TH Pl
-10 1.21 0.54 1.16 0.57 1.12 0.60
-7 1.30 0.55 1.25 0.58 1.21 0.61
-2 1.38 0.56 1.33 0.59 1.29 0.62
2 1.68 0.58 1.61 0.62 1.54 0.66
6 2.37 0.63 2.30 0.67 2.22 0.71
10 2.58 0.66 2.51 0.71 2.44 0.76
15 2.78 0.69 2.71 0.74 2.65 0.79
20 2.93 0.71 2.86 0.77 2.78 0.83
LEGEND
TH – Total Heating Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OD – Outdoor
