Electra Alpha 7 - Page 32

5-7
PERFORMANCE DATA & PRESSURE CURVES
SM ALPHA 1-E.3 GB
5.4 Alpha7 DF / GCN7 RC R410A A2
5.4.1 Cooling
Discharge Pressure VS.Outdoor Temp
12
14
16
18
20
22
24
26
28
30
32
34
36
15 20 25 30 35 40 46
Outdoor Temp.(DB
o
C )
Discharge Pressure (Bar[g])
15/21(WB/DB ºC)
17/24(WB/DB ºC)
19/27(WB/DB ºC)
21/29(WB/DB ºC)
23/32(WB/DB ºC)
Suction Pressure VS.Outdoor Temp
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
15 20 25 30 35 40 46
Outdoor Temp.(DB
o
C )
Suction Pressure (Bar[g])
15/21(WB/DB ºC)
17/24(WB/DB ºC)
19/27(WB/DB ºC)
21/29(WB/DB ºC)
23/32(WB/DB ºC)
