Electra Wmz 9 - Optional Accessories

5-5
PERFORMANCE DATA & PRESSURE CURVES
Revision Y05-01Service Manual - WMZ
5.4 WMZ 9 GCZ 9 R22
5.4.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
ENTERING AIR DB
OU COIL (°C)
DATA
ENTERING AIR WB/DB ID COIL ( °C)
15/21 17/24 19/27 21/29 23/32
15
(1)
TC
2.69 2.78 2.85 2.92 2.96
SC
1.66 1.74 1.80 1.85 1.88
PI
0.71 0.71 0.71 0.71 0.72
20
(1)
TC
2.60 2.74 2.83 2.89 2.96
SC
1.63 1.72 1.79 1.84 1.88
PI
0.77 0.77 0.77 0.78 0.78
25
TC
2.46 2.66 2.79 2.88 2.95
SC
1.59 1.69 1.78 1.83 1.86
PI
0.83 0.84 0.84 0.85 0.85
30
TC
2.30 2.51 2.71 2.80 2.89
SC
1.54 1.64 1.74 1.79 1.83
PI
0.90 0.91
0.92
0.93 0.93
35
TC
2.13 2.31
2.55
2.68 2.80
SC
1.46 1.57 1.70 1.75 1.78
PI
0.97 0.98
1.00
1.01 1.01
40
TC
1.94 2.11
2.30
2.52 2.65
SC
1.38 1.49 1.61 1.66 1.69
PI
1.04 1.06 1.08 1.09 1.10
46
TC
1.68 1.84 2.02 2.23 2.41
SC
1.27 1.36 1.47 1.52 1.55
PI
1.14 1.16 1.18 1.20 1.21
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, refer to Optional Accessories (Chapter 15).
