2-1
PRODUCT DATA SHEET
Revision Y05-01Service Manual - WMZ
1. PRODUCT DATA SHEET
1.1 R407C
Model Indoor Unit WMZ-7
Model Outdoor Unit GCZ-7
Installation Method of Pipe Flared
Characteristics Units Cooling Only Cooling Heating
Capacity
(1)
Btu/hr 6860 6860 7640
kW 2.01 2.01 2.24
Power input
(1)
kW 0.77 0.77 0.72
EER (Cooling) or COP(Heating)
(1)
W/W 2.61 2.61 3.11
Energy efficiency class
D
DD
Power supply V/Ph/Hz 230V/Single/50Hz
Rated current A 3.4 3.4 3.2
Starting current A 22
Circuit breaker rating A 10
INDOOR
Fan type & quantity Cross flow x 1
Fan speeds H/M/L RPM 970/750
Air flow
(2)
H/M/L m3/hr 360/275
External static pressure Min-Max Pa 0
Sound power level
(3)
H/M/L dB(A) 47/41
Sound pressure level
(4)
H/M/L dB(A) 34/28
Moisture removal l/hr 0.8
Condensate drain tube I.D mm 16
Dimensions WxHxD mm 815*280*170
Weight kg 8
Package dimensions WxHxD mm 890*240*340
Packaged weight kg 11.5
Units per pallet units 32
Stacking height units 8 levels
OUTDOOR
Refrigerant control Capillary tube
Compressor type, model Rotary, TOSHIBA PG135X1C-4DT2
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 555
Air flow H/L m3/hr 1310
Sound power level H/L dB(A) 63
Sound pressure level
(4)
H/L dB(A) 53
Dimensions WxHxD mm 760*545*245
Weight kg 30 31
Package dimensions WxHxD mm 880*610*310
Packaged weight kg 32.5
Units per pallet Units 12
Stacking height units 3 levels
Refrigerant type R407C
Refrigerant chargless distance kg/m 0.59kg/4m
Additional charge per 1 meter g/m 4m<Lin<8m:+5g/m Lin>8m:+9g/m
Connections between
units
Liquid line In.(mm) Ф 1/4”(6.35)
Suction line In.(mm) Ф 3/8”(9.53)
Max.tubing length m. Max.10
Max.height
difference
m. Max.7
Operation control type Remote control
Heating elements kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
