Electra WNG 9 - Indoor Unit WNG 9 LCD

14-3
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-03Service Manual - WNG
14.1.3 Indoor Unit WNG 9 LCD
Item Code Item Desc Quantity
Drawing
Number Effective From Effective To
4526942 Grille C 1 1C 26-Feb-04 Active
4527025 LCD Display Assy 1 2 26-Feb-04 Active
4518655 Air filter 2 3 26-Feb-04 Active
4519132 ACTIVE CARBON FILTER ASSY 1 4 21-Sep-04 Active
4519744 Low temperature catalys 1 4 21-Sep-04 Active
4527029 Front Frame Assy 1 5 26-Feb-04 Active
4526946 (LCD) Display Lens Assy(LCD) 1 6 26-Feb-04 Active
4526952 Screw Cover 2 7 26-Feb-04 Active
433133 IONIZER DISPLAY 906-191-07 1 8 26-Feb-04 Active
4527335 Coil, Indoor unit WNG-7/9 R410A 1 9 26-Feb-04 01-Sep-04
4527173 EVAPORATOR ASSY WNG7/9 R410A 1 9 01-Sep-04 Active
4518664 Drain hose 1 11 26-Feb-04 Active
4518682 Gear BOX ASSY 1 12 26-Feb-04 Active
4527434 Air Outlet Assy 1 13 26-Feb-04 Active
4518646 LOUVER SUPPORT 2 14 26-Feb-04 Active
4518638 Upper Louver 1 15 26-Feb-04 Active
4526953 Lower Louver 1 16 26-Feb-04 Active
4518642 VERT LOUVER LINK 1 17 26-Feb-04 Active
4518640 Vert. Louver A 2 18 26-Feb-04 Active
4518641 Vert. Louver B 10 18 26-Feb-04 Active
4518643 VERT. LOUVER LOCK 1 1 19 26-Feb-04 Active
4518644 VERT. LOUVER LOCK 2 1 19 26-Feb-04 Active
4518645 VERT. LOUVER LOCK 3 1 19 26-Feb-04 Active
4518662 Bearing assy fan 1 20 26-Feb-04 Active
4518661 Fan assy plastic D91 1 21 26-Feb-04 Active
4518730 Rear panel assy 1 22 26-Feb-04 Active
4518656 MOUNTING HOOK 2 23 26-Feb-04 Active
4518657 TUBE LOCK 1 24 26-Feb-04 Active
4518670 Installation Plate 1 25 26-Feb-04 Active
4518654 TUBE BRACKET 1 26 26-Feb-04 Active
4519864 20W PG Motor 1 27 26-Feb-04 Active
4518651 Cover Side Motor 1 28 26-Feb-04 Active
4518650 Motor Cover 1 29 26-Feb-04 Active
4519365 STEP MOTOR CABLE B 1 30 26-Feb-04 Active
4518737 STEP MOTOR CABLE A 1 31 26-Feb-04 Active
4518679 STEP MOTOR 2 32 26-Feb-04 Active
452969500 Step Motor B 1 33 23-Jul-05 Active
4521158 Power cord cable 1 33 26-Feb-04 Active
4519900 IONIZER CABLE A 1 34 26-Feb-04 Active
452969400 Step Motor A 1 35 23-Jul-05 Active
433134 IONIZER POWER 906-191-01 1 35 26-Feb-04 Active
4518868 TRANSFORMER 1 36 26-Feb-04 Active
4527028 NWNG-9(LCD,HuaLian) NWNG-9 1 37 26-Feb-04 Active
4518663 ELECTROSTATIC FLITER WNG-1 1 38 26-Feb-04 Active
4526950 Wire Cover 1 39 26-Feb-04 Active
4519365 STEP MOTOR CABLE B 1 None 23-Jul-05 23-Jul-05
4518737 STEP MOTOR CABLE A 1 None 23-Jul-05 23-Jul-05
4518679 STEP MOTOR 2 None 23-Jul-05 23-Jul-05
