Electra WNG 9 - Outdoor Unit ONG 7 ST

14-17
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-03Service Manual - WNG
14.1.17 Outdoor Unit ONG 7 ST
Code Item Desc Quantity
Drawing
Number Effective From Effective To
433218 Front Panel A 1 1 05-Mar-04 Active
433221 Air Inlet Ring-420 1 2 05-Mar-04 Active
433223 Painting Insulation Plate 1 3 05-Mar-04 Active
4519251 Axial Fan OD=400 1 4 05-Mar-04 Active
4526591 Motor YYK30Z-6 1 5 05-Mar-04 Active
433215 Motor Support 1 6 05-Mar-04 12-Mar-04
4527203 Motor Support 1 6 12-Mar-04 Active
4519601 Base Painting Assy. 1 7 05-Mar-04 12-Mar-04
4526747 Base Painting Assy. 1 7 12-Mar-04 Active
433217 Partition Plate 1 8 05-Mar-04 Active
455000502 Compressor Capacitor 35uF With Screw 1 9 05-Mar-04 Active
4519611 Electric Panel Painting Plate 1 10 05-Mar-04 Active
4524176 1/4 Liqiud Valve(R410A) 1 11 05-Mar-04 Active
4524177 3/8 Gas Valve(R410A) 1 12 05-Mar-04 Active
455000000 single patch Capacitor for fan 1 13 05-Mar-04 Active
4514588 5 Poles terminal block 1 14 05-Mar-04 Active
204107 Cable clip Nylon 1 15 05-Mar-04 Active
236179 2 Poles terminal block 1 16 05-Mar-04 11-Mar-04
4516637 Out sensor Black 1 17 05-Mar-04 11-Mar-04
4526614 Capillary 1 19 05-Mar-04 02-Sep-04
4526606 Capillary Assy.(ST) 1 19 02-Sep-04 Active
4525650 Charge tube 1 20 05-Mar-04 Active
4526608 Compressor Jacket 1 21 05-Mar-04 12-Mar-04
452799600 Compressor Jacket ONG3-7 1 21 12-Mar-04 Active
4519610 Compressor Isolation. Top Cover 1 22 05-Mar-04 11-Mar-04
4514091 Grommet 3 23 05-Mar-04 Active
4510677 Nut With Flange M8 -D=24 3 24 05-Mar-04 Active
4519987 Wire assy 1 25 05-Mar-04 12-Mar-04
4527008 Wire assy 1 25 12-Mar-04 Active
4526578 Compressor Assy. LG GK086P 1 26 05-Mar-04 Active
4514088 Gasket 1 27 05-Mar-04 Active
4516824 Cover Terminal 1 28 05-Mar-04 Active
4514089 Nut hex 1 29 05-Mar-04 Active
433229 cover valve 1 30 05-Mar-04 Active
433234 Clamp 1 31 05-Mar-04 Active
4518950 Filter Drier BFK-053S 1 31 05-Mar-04 11-Mar-04
4519606 Right side panel (painting plate) 1 32 05-Mar-04 Active
4527323 2 Discharge Pipe Assy. 2 (7ST) 1 33 11-Mar-04 Active
4526574 Suction Tubing 1 (7ST) 1 34 05-Mar-04 Active
433228 Back Side Net 1 35 05-Mar-04 Active
433216 Bridge 1 36 05-Mar-04 Active
433235 SPACER A 22*1 1 37 05-Mar-04 11-Mar-04
4526615 Condensor Soldering Assy 1 38 05-Mar-04 Active
4519614 Painting Top Cover 1 39 05-Mar-04 Active
4519300 Nut M5 L 1 40 05-Mar-04 Active
433225 Handle 1 41 05-Mar-04 Active
4519607 Left Side Panel Painting Plate 1 42 05-Mar-04 Active
4526573 Discharge Tubing 1 43 05-Mar-04 11-Mar-04
