14-8
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-03 Service Manual - WNG
14.1.8 Indoor Unit WNG 21 LCD
No. Item Code Item Desc Qty
8 433133 IONIZER DISPLAY 906-191-07 1
32 433134 IONIZER POWER 906-191-01 1
4 4518113 AIR FILTER ASSY 1
26 4518651 Cover Side Motor 1
22 4518657 TUBE LOCK 1
19 4518662 Bearing assy fan 1
10 4518664 Drain hose 1
28 4521197 remote controller RC3 1
36 4524963 Electrostatic Filter 1
34 4524967 IONIZER WIRE A 1
31 4526201 IONIZER CABLE B 1
6 4526946 Display Lens Assy(LCD) 1
11 452917300 Air outlet 1
1 452917400 Grill C/WNG18 1
14 452917500 Horizontal flap A 1
15 452917600 Horizontal flap B 1
17 452918200 Vertical flap B 2
18 452918300 Tie/vertical flap A 1
18 452918400 Vertical flap stator B 2
16 452918500 Linkage A 1
16 452918600 Linkage B 1
13 452918700 Support/horizontal louver 1
27 452918800 Cover/motor 1
24 452919400 Joint/Unit housing 1
37 452919500 Cover/terminal 1
7 452919600 Screw cover 3
3 452919800 Filter 2
23 452920100 Mount bracket/WNG-18 £¨20£© 1
17 452930700 Vertical flap A 12
18 452953000 Vertical flap stator C 1
25 453024500 PG Motor 1
20 453024900 Impeller fan 1
2 453049500 LCD Display Assy. 1
12 453050200 STEP MOTOR A 1
29 453050300 STEP MOTOR B 1
35 453051000 WNG24(LCD,HuaLian) WNG24 1
21 453053800 Base assy./WNG18 1
11 453053900 Air outlet assy./WNG18 1
5 453054000 Frame assy./WNG18 1
30 453057900 Gear BOX ASSY 1
33 453232400 Power Cord Without Plug/ E 1
9 453260400 Evaporator Assy/WNG24 1
