14-44
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-03 Service Manual - WNG
14.1.44 Outdoor Unit OU7-24 ST 1PH
SP No. Part No. Description Qty
13 190443 HEATER CRANKCASE MITSUBISHI CO 1
22 402283 SUCTION ACCUMULATOR 3"x5/8" 3. 1
17 402495 BOARD TPHN 5B 1
2 433280 SIDE PANEL OU7-24 R410A 1
10 433281 SIDE GUARD OU7-24 R410 1
14 433293 COMPRESSOR NN27VBAMT 1
6 433705 NEW BASE ASSY OU 2005 LOCAL R4 1
44 433816 SUCTION ASSY OU7 R410A 1
16 433817 TUBING ASSY OU7 ST R410A 1
15 433845 CAPILLARY ASSY OU7-24 ST R410A 1
7 433846 COIL OU7-24 ST 1
45 433847 GAS VAVE ASSY OU7 ST R410A 1
9 434062 MOTOR 86W,2S,OU7-24 1
19 434716 THERMISTOR+CAP WTH CONNECTOR L 1
3 436357 SMALL ELECTRICAL COVER OU 1
11 436358 OU LEADING HANDLE 1
1 437045 UPPER COVER EL13 OU LARGE 1
5 437091 OU SQUARE FAN GUARD 1
24 437229 ELECTRICAL BOX TPHN 1
21 437274 COMPRESOR WIRING OU7/8-1PH MIT 1
4 439329 FRONT COVER/CO' OU7-35/90 EL13 1
12 439342 MOTOR SUPPORT OU7 1
18 442007 CAPACITOR 6mF 400V P1/P2 1
20 442016 CAPACITOR 55mF 400V P1/P2 1
8 4529604 AXIAL FAN D493*143 1
