Model Indoor Unit WNG-30
Model Outdoor Unit GC-30
Installation Method of Pipe Flared
Characteristics Units cooling only Cooling Heating
Capacity
(1)
Btu/hr 29000 29000 32410
kW 8.5 8.5 9.5
Power input
(1)
kW 3.1 3.1 3.25
EER (Cooling) or COP(Heating)
(1)
W/W 2.74 2.74 2.92
Energy efficiency class A A B
Power supply V/Ph/Hz 230V/Single/50Hz
Rated current A 13.7 13.7 14.2
Starting current A 73
Circuit breaker rating A 25
INDOOR
Fan type & quantity Crossflow x 1
Fan speeds H/M/L RPM 1250/1050/850
Air flow
(2)
H/M/L m3/hr 1300/1050/900
External static pressure Min-Max Pa 0
Sound power level
(3)
H/M/L dB(A) 65/61/57
Sound pressure level
(4)
H/M/L dB(A) 52/48/44
Moisture removal l/hr 4
Condenstate drain tube I.D mm 16
Dimensions WxHxD mm 1200X340X236
Weight kg 18.5
Package dimensions WxHxD mm 1305X430X325
Packaged weight kg 24
Units per pallet units 12
Stacking height units 6 levels
OUTDOOR
Refrigerant control Capillary tube restrictor for heating)
Compressor type,model Scroll,LG SQ040PAA
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 880
Air flow H/L m3/hr 3200
Sound power level H/L dB(A) 71
Sound pressure level
(4)
H/L dB(A) 61
Dimensions WxHxD mm 950*340*835
Weight kg 87 90
Package dimensions WxHxD mm 1080*477*910
Packaged weight kg 105
Units per pallet Units 9
Stacking height units 3 levels
Refrigerant type R22
Refrigerant chargless distance kg/m 2.39kg/7.5m
Additional charge g/m 7.5m<Lin<30m:+25g/m
Connections between
units
Liquid line In.(mm) 3/8”(9.53)
Suction line In.(mm) 5/8”(15.88)
Max.tubing length m. Max.30
Max.height
difference
m. Max.20
Operation control type Remote control
Heating elements kW 0.3
Others
(1)
Rating conditions in accordance with ISO 5151, ISO 13253 (for ducted units) and EN 14511.
(2)
Airflow in ducted units; at nominal external static pressure.
(3)
Sound power in ducted units is measured at air discharge.
(4)
Sound pressure level measured at 1 meter distance from unit.
