14-126
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-03 Service Manual - WNG
14.3.23 Outdoor Unit ONG3 14 RC
Item Code Item Desc Quantity
Drawing
Number Effective From Effective To
433218 Front Panel A 1 1a 09-Aug-02 Active
433221 Air Inlet Ring-420 1 2 09-Aug-02 Active
433223 Painting Insulation Plate 1 3 09-Aug-02 Active
4519251 Axial Fan OD=400 1 4 09-Aug-02 Active
4519692 Fan Motor (810rpm) 1 5 09-Aug-02 Active
433215 Motor Support 1 6 09-Aug-02 Active
4519601 Base Painting Assy. 1 7 09-Aug-02 Active
433217 Partition Plate 1 8 09-Aug-02 Active
233307 Cap. 35uF/400V(Instead by 4517993) 1 9 09-Aug-02 31-May-04
455000504 Compressor Capacitor With Screw 1 9 31-May-04 Active
4519611 Electric Panel Painting Plate 1 10 09-Aug-02 Active
4519265 Liquid Valve OD=6.35 1 11 09-Aug-02 Active
4519266 GAS VALVE OD=12.7 1 12 09-Aug-02 Active
4517990 Cap. 2uF/450V 1 13 09-Aug-02 08-Jan-04
455000001 single patch Capacitor for fan 1 13 08-Jan-04 09-Feb-04
455000108 Double patch Capacitor for fan 1 13 09-Feb-04 Active
236332 6 Poles terminal block 1 14 09-Aug-02 Active
204107 Cable clip Nylon 1 15 09-Aug-02 Active
236179 2 Poles terminal block 1 16 09-Aug-02 Active
4516637 Out sensor Black 1 17 09-Aug-02 Active
4519931 Filter 1 18 09-Aug-02 Active
4519621 Capillary Assy 1 19 09-Aug-02 Active
4510463 Charge tube T2M 6.35x0.7 1 20 09-Aug-02 Active
4520367 Compressor Jacket (LG292) 1 21 09-Aug-02 Active
4520354 Comp. Insu.Top Cover (LG292) 1 22 09-Aug-02 Active
4514091 Grommet 3 23 09-Aug-02 Active
4513974 Nut M8 3 24 09-Aug-02 13-Mar-03
4519987 Wire assy 1 25 09-Aug-02 Active
4516603 Comp assy. QJ292PD23A LG T 1 26 09-Aug-02 29-Oct-03
4516578 Compressor assy. QJ292PT23A LG T 1 26 29-Oct-03 Active
4516826 Rubber washer 1 27 09-Aug-02 Active
4516825 Cover Terminal 1 28 09-Aug-02 Active
4514089 Nut hex 1 29 09-Aug-02 Active
433261 Valve Cover 1 30 09-Aug-02 Active
433266 Fresh Air Cover 1 31 09-Aug-02 Active
4520033 Brushless DC Fan Motor FLW100-22A 1 32 09-Aug-02 Active
433268 Fresh Air Filter 1 33 09-Aug-02 Active
4520011 15VDC Transformer 1 34 09-Aug-02 Active
433265 Fresh Air Base 1 35 09-Aug-02 Active
433269 Fresh Air Nipple 1 36 09-Aug-02 Active
433267 Fresh Air Pipe 1 37 09-Aug-02 Active
433234 Clamp 1 38 09-Aug-02 19-Jul-04
452892900 Wire Clip 1 38 19-Jul-04 Active
4520031 Right side panel (painting plate) 1 39 09-Aug-02 Active
4519624 4-Way Valve soldering Assy. 1 40 09-Aug-02 Active
433228 Back Side Net 1 43 09-Aug-02 Active
433216 Bridge 1 44 09-Aug-02 Active
433241 SPACER A 19*2 1 45 09-Aug-02 Active
4521781 Condenser Soldering Assy. 1 46 09-Aug-02 Active
4519614 Painting Top Cover 1 49 09-Aug-02 Active
4519300 Nut M5 L 1 50 09-Aug-02 Active
433225 Handle 1 51 09-Aug-02 Active
4519607 Left Side Panel Painting Plate 1 52 09-Aug-02 Active
4510677 Nut With Flange M8 -D=24 3 None 13-Mar-03 Active
4526921 Bracket washer 1 None 29-Dec-03 Active
