SCOREBOARD OPERATION
SCOREBOARD STARTUP
1. Place the power disconnect for the scoreboard in the ON position.
2. Plug one end of the 10 ft. extension cable into ¼” stereo jack on the junction box.
3. Plug the other end into the ¼” stereo jack mounted on the control console back plate.
4. Plug the control console power cord into a grounded NEMA 5-15R 120 VAC
receptacle.
GAME TIME OPERATION
This scoreboard is operated with a 15-key control console. Figure 11 shows the keypad
layout on the control console.
Electo-Mech
800-445-7846
www.electro-mech.com
CLOCK
ON /
OFF
SEC
+1
SEC
-1
MIN
-1
GUEST
+10
GUEST
+1
HOME
+10
HOME
+1
NEW
GAME
CLOCK
RESET
DOWN
YTG
RESET
Scoreboard Co.
FOOTBALL
BASEBALL
BALL
YTG
-10
STRIKE
YTG
-1
OUT
QTR
INNING
Figure 11 Keypad Layout
The scoreboard will display:
GUEST SCORE – 0
HOME SCORE – 0
CLOCK – 30:00
