Electro-mech 1360 - Page 23

1360 Page 23
Electro-Mech Scoreboard Co. • 120 Industrial Parkway • Wrightsville, GA 31096
Phone: (800) 445-7846 • Fax (478) 864-0212 • Email: score@electro-mech.com
J1
J2
J3
1/2 A
Not a convenience receptacle
This receptacle is designed for use with
Electro-Mech control consoles only.
E
S
U
F
E
S
U
F
E
S
U
F
F6
F3
F4
F5
F1
F2
3 Industrial Parkway, Wrightsville, GA 31096
Scoreboard Company
Electro-Mech
800-445-7846 www.electro-mech.com
Replace with fuses of same type and rating only.
Test Jack
Model:
Serial Number:
LPS5
JAN 2003
U
F
S
E
E
S
3A 10A 10A
F
U
S
E
U
F
E
S
S
E
U
F
1/2A 1A
F
U
F
E
U
S
U
S
E
F
U
F
E
S
U
F
E
F
U
S
E
S
J4
J5
Figure 18 LPS5 Fuse Locations
LPS5 FUSES
FUSE
RATING
FUNCTION
BUSSMAN PART #
F1
3A 250V
TRANSFORMER PRIMARY
AGC-3
F2
10A 250V
DRIVER MODULE DC POWER INPUT #1
AGC-10
F3
10A 250V
DRIVER MODULE DC POWER INPUT #2
AGC-10
F4
½A 250V
SERIAL DATA ISOLATION RELAY
AGC-1/2
F5
1A 250V
HORN
AGC-1
F6
½A 250V
120 VAC ELECTRICAL RECEPTACLE
AGC-1/2
Note: Other manufacturer’s fuses may be substituted for the Bussmann fuses.
