Electro-Voice EVOLVE-30M - Technical Data

36 en | Technical data EVOLVE Portable Column Loudspeaker
2020-04 | v04 | F.01U.381.064 User manual Electro-Voice
10 Technical data
Frequency response (-3 dB)
1
: 51 Hz to 20 KHz
Frequency range (-10 dB)
1
: 45 Hz to 20 KHz
Maximum SPL
2
: 123 dB
Coverage (H x V): 120° x 40°
Amplifier rating: 1000 W
LF channel rating: 500 W
HF channel rating: 500 W
Crossover frequency: 200 Hz
Connectors: 4x XLR/TRS Combo Jack Line / Mic Input
1x 1/4" TRS HI-Z input
2x XLR/TRS Combo Jack for Stereo Line Input
1x Stereo RCA Input
1x 3.5 mm Stereo Input
1x Wireless Stereo Bluetooth® Audio Input
1x 1/4" Foot Switch Input
1x XLR MIX OUT Output
1x XLR AUX OUT Output
Enclosure: Sub: 15 mm plywood
Column: Composite
Pole: Aluminum
Grille: Steel with black or white powder coat
Color: Black or white
Dimensions (HxWxD):
mm (in)
Sub: 448 x 332 x 432 (17.6 x 13.1 x 17)
Column: 620 x 95 x 157 (24.4 x 3.7 x 6.2)
Pole (2 pcs): 600 x 48 x 55 (23.6 x 1.9 x 2.2)
Net weight: Sub: 34.9 lb (15.8 kg)
Column: 6.0 lb (2.7 kg)
Pole (2 pcs): 3.1 lb (1.4 kg)
Bag for column and pole: 1.9 (0.85 kg)
Shipping weight: 53.4 lb (24.2 kg)
Frequency Band: 2402 MHz to 2480 MHz
Transmitter Power: EIRP:4.8 dBm
Power consumption
3
: 100-240 V AC, 50-60 Hz, 1.5-0.6 A
1
Half-space measurement using live DSP preset.
2
Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
3
Current rating is 1/8 power.
