11
Stopping or interrupting a self-cleaning cycle 91
To start the delayed self-clean cycle 92
To set the control for the self-cleaning cycle to
start at a delayed time and shut off automatically 92
When the self-clean cycle is completed 92
Adjusting oven temperature 93
To adjust oven temperature 93
Failure modes 93
How the PRC Glass touch electronic oven control works 94
Capacitance touch glass 94
Preheat 94
Bake 94
Timed bake 94
Convection bake 94
Convection roast 94
Broil 94
Clean 95
Calibration 95
To check oven calibration 95
To change the calibration 95
To adjust the oven temperature lower 95
Troubleshooting 95
F1 code 95
F3 code 95
F9 code 96
Control will not program 96
Time bake does not operate 96
Convection bake 96
Fan motor does not operate 96
Convection element does not heat 96
Control does not operate in preheat 96
Blank display 96
Bake element does not heat 96
Broil element does not heat 96
Oven door does not lock when the oven
is programmed for clean 97
Oven door locks but the oven does not heat 97
Door latch is partly closed with door open 97
Sample schematic for PRC Glass touch control system 98
Warmer drawer 99
To set the warmer drawer thermostat control 99
How the warmer drawer circuit works 99
Troubleshooting 99
If the element does not heat 99
If the element heats during preheat, then stays
off until the temperature drops to about 130° F 100
If the element does not cycle off 100
If the warmer drawer is slow preheating 100
If the warmer drawer heats, but the
indicator light does not glow 100
SECTION E - 30” DISASSEMBLY AND REPLACEMENT OF PARTS 101 - 122
Top trim on backguard area 101
Removing the 15 amp fuse 101
Removing the fluorescent lamp starter 101
To roll the control mounting panel forward 101
Removing the 120 volt outlet 101
Removing the oven light or fluorescent switch 102
