122
2. Remove the two screws holding the bodyside to the
rear panel. Lift the rear of bodyside to disengage it
from the four shoulder screws holding the bodyside
to the range frame.
Four shoulder screws
Removing the door switch:
1. Disconnect power and remove the righthand
bodyside.
2. Disconnect the wires and remove the two screws
holding the switch to the heat shield.
Two screws
Removing the hinge roller brackets:
1. Disconnect power and remove the oven door and
the bodyside that the hinge roller bracket is on.
2. Remove the two screws holding the bracket to the
front frame and remove the bracket through the
bodyside opening.
Two screws
