13
Warmer drawer area 115
Removing the warmer drawer 115
Removing the drawer seal 115
Removing the outer drawer panel 115
Removing the inner drawer panel 115
Removing side rail on from the drawer 116
Removing the drawer glides 116
Removing the wamer drawer element 116
Removing the warmer drawer thermostat 116
Removing the diode and warmer element terminal cover 117
Removing the warmer drawer diode 117
Removing the warmer drawer cavity 117
Removing the top of the warmer drawer cavity 118
Removing the bottom of the warmer drawer cavity 118
Removing the front roller 118
Removing the front roller bracket 118
Removing the rear roller 118
Removing the leveling leg and roller assembly 119
Removing the wool shield 119
Components mounted to the rear of the range 119
Removing the large rear panel 119
Removing small panel 120
Removing the oven thermo cutout 120
Removing the fluorescent light ballast 120
Removing the convection fan or speed bake motor 120
Removing the lock motor assembly 121
Removing the power supply cord 121
Removing the bodyside 121
Removing the door switch 122
Removing the hinge roller brackets 122
SECTION E - 40” DISASSEMBLY AND REPLACEMENT OF PARTS 123 - 138
Top trim on backgurad area 123
Removing the fluorescent light bulb 123
Removing the fluorescent light starter 123
Removing backguard backpanel 123
Removing the fluorescent light socket 123
Removing the fluorescent ballast 123
Removing the thermostat and top element knobs 124
Removing top element switch 124
Removing the small oven thermostat 124
Removing indicator lights 125
Removing the light switches 125
Removing the electronic oven control 125
Removing the end cap 125
Removing the control panel end bracket 125
Removing the control panel 126
Main top area 126
Removing coil elements and drip pans 126
Removing the terminal block 126
Removing the main top 126
Removing rear hinge 127
Removing the lock rod 127
Removing the oven door latch plate 127
Removing the small oven door hinges 127
Removing the front oven trim 128
Large oven door area 128
Removing the large oven door’s door seal self-clean models 128
