Electrolux 7000 - Component Resistance Chart

10
QUICK REFERENCE SHEET
Component Resistances*
Drive motor (120 volt, 60 Hz, 1/4 h.p. 1725 rpm)
Motor Start Winding
Motor Run Winding
Heating Element
Control Thermistor
Burner Assembly
Ignitor
Secondary Coil
Booster Coil
Electric Models
4.5 Ohms
3.8 Ohms
12.8 Ohms
50K Ohms +/- 5% @ 77° F
---
---
---
Gas Models
4.5 Ohms
3.8 Ohms
50K Ohms +/- 5% @ 77° F
50 - 400 Ohms
1200 Ohms
1320 Ohms
* +/- 10% @ 77° F
