67
Removing the loading door:
Note: To remove the two screws holding the
hinge of the door to the front panel, use a
small ratchet with a #2 square bit or a
right angle Phillips screwdriver.
1. Open the dryer door.
2. Remove the (2) screws that secure the hinge to the
front panel. NOTE: Remove the bottom screw first.
Support the door assembly firmly before removing
the top screw.
3. Remove the door assembly by lifting and pulling
outward from unit.
4. Place door assembly face down on a soft flat
surface.
Removing the button spring:
1. Disconnect dryer from the electrical supply and
remove the control board.
2. Releasethe lockingtab andlift the spring up and out.
Removing the buttons:
1. Disconnect dryer from the electrical supply and
remove the control board and the button spring.
2. With the button spring removed, the buttons will lift
out.
