Gas dryer completely inoperative.
Note: Always check wiring to the components.
Note: If a fault code is displayed, the dryer will not operate.
Dryer completely
inoperative.
Does the control beep or
the LED flash when the
start button is pushed.?
No.
Defective household
power supply or
broken wire between
dryer terminal block
and thermal limiter.
Yes.
Measure the voltage drop
between pins 1 & 2 of the
eight pin plug of the wire
harness to the control
board.
0.
120VAC.
Defective control
board.
Is an error
code display.
No.
Refer to error
code chart.
Yes.
Measure the voltage drop
between pins 1 & 2 of J-4
120VAC.
Defective control
board.
Defective door
switch.
0.
Check the resistance of the
control thermistor at room
temperature.
50,000 Ohms +/- 10%.
Defective
electronic
control.
Defective
thermistor.
More or less
than 50,000
Ohms +/- 10%.
>120VAC - 0<
To Next Page
