41
NOTE: If washer was previously installed, disconnect
the power cord, remove the inlet hoses from the water
faucets and tape the drain hose to the top of the washer
to eliminate excess water on the floor.
4. Using two or more people, carefully lift the washer
onto the pedestal, tilting the washer back slightly to
align the holes in the rear of the washer with the slots
of the rear brackets on the pedestals. See Pictures 5
and 6.
NOTE: If the mounting holes do not align, make sure
the washer leveling legs are adjusted fully into
the washing machine. Turn each leg tight to
the base.
5. Set the washer down onto the pedestal making sure
the washer base is behind the front brackets of the
pedestal. See Picture 7.
6. Align the sides of the washer with the sides of the
pedestal and attach the washer to the rear brackets
using four #10 screws (2 per bracket) as shown in
Picture 8.
Picture 5
Picture 6
Picture 7
Picture 8
Picture 4
