Electrolux Compact - Housing and Component Access; Housing Removal Procedure; Internal Component Locations

- 27 -
Spares Operation - R.Kurzke 02/03 599 516 219 EN
Housing
After removing the housing screws (lay the machine on its side) from the bottom of the
machine, the housing is unclipped front and back from the catches and can be removed.
All components from the left and right side are now accessible.
You need
screwdriver
Torx TX20
Programmer / Timer
Thermostats
Rinse-aid dispenser
Interference filter
Coil for
detergent dispenser
Pressure switch
Drain pump
anti-siphon valve
Softener
Air chamber
