Float switch
The float switch is snapped out with
a small screwdriver and can be
taken out of its mounting.
After removing the protective cap,
the microswitch can be snapped
out.
Switch unit
The switch unit is secured by means of screws and easily to
remove.
Inlet valve
The inlet valve is mounted in the same place as the float switch.
After the removal of the hose, the valve can be drawn out of the
chassis with suitable pliers.
The mounting for the thermostats is screwed at the right side of the air chamber. After its release, the
thermostats can be removed.
Thermostats
