Component Teardown and Testing
4-9
Figure 4-8. Door Removal
Pin
Pin
Upper
Oven Hinge
Upper Oven
Hinge
Lower Oven
Hinge
Lower
Oven Hinge
Choke Cover
Sealer Film
Installation
1. Put the adhesive tape on the backing film of the
sealer film as shown in Figure 4-9.
2. Tear the backing film by pulling the adhesive tape.
3. Put the pasted side of the sealer film on the door
panel.
Figure 4-9. Door Removal
Sealer Film
Backing Film
Adhesive Tape
