EUROFLEC 19/36
4.6. Defrosting heaters
The two heating elements are connected in parallel:
- the defrosting heater (250 W) melts the ice which builds up on the evaporator battery.
- the drainage duct heater (43.5 W) prevents the formation of ice in the drainage duct.
DEFROSTING HEATER DRAINAGE DUCT HEATER
4.7. NTC Sensors
This appliance is fitted with two NTC sensors, both located in the freezer compartment:
- the external (in air) NTC sensor governs the operating cycles of the compressor (switching on and off).
- the evaporator NTC sensor is used for :
- terminating the defrosting cycle by switching off the heating elements when the temperature reaches
15°C;
- starting the forced defrosting cycle when the temperature detected is below –35°C.
The two NTC sensors are connected together as one component, therefore they are not available as single
spare part.
°C Ohm
10
5348 ±0.6
5
6818 ±0.4
0
8758 ±0.4
-5
11337 ±0.4
-10
14795 ±0.6
-15
19475 ±0.7
-20
25862 ±0.8
-25
34666 ±0.9
-30
46921 ±1
-35
64161 ±1
-40
88577 ±1
4.8. Overheating protection
In case of a malfunction of the control of the end-of defrosting temperature (+15° C), two thermal cut-outs
fitted to the evaporator battery switch the heating elements off at a temperature of +55°C.
The two thermal cut-outs are connected together as one component, therefore they are not available as
single spare part.
4.9. Freezer compartment light
According to the model, 2 normal lamps or 1 halogen lamp supply the light on the freezer compartment.
