SOI/DT 2007-02 dmm 53/56 599 38 60-23
g. Loosen the screws which secure the cross-member to the cabinet.
h. Release the hook which secures the dispenser to the cross-member.
i. Lift the control panel up.
j. Loosen the screws which secure the cross-member to the control
panel.
k. Release the hook which secures the control panel to the cross-
member.
l. Turn and insert a protection between the control panel and the
surface which you lean it on to avoid damaging it.
m. To extract the board, remove the screws which secure it to the control
panel.
n. To remove the button springing system, release the two hooks which
secure it to the main board.
g
h
h
i
j
k
m
n
