ENV06 EWM11xx EWM21xx EWM25xx/35xx
QUICK GUIDE AND APPLIANCES LIST 67/176 599 72 40-80
3.16.1 Key to circuit diagram EWM25xx without Aqua Control
Electrical components on appliance Components on main board
1. LCD Module
2. Damper with weight sensor
3. Flowmeter
4. Analogic pressure switch
5. Washing NTC temperature sensor
6. Solenoid valve for prewash
7. Solenoid valve for wash
8. Solenoid valve for bleach
9. Thermal cut-out (circulation pump)
10. Pump circulation
11. Thermal cut-out (drain pump)
12. Drain pump
13. Motor control board (FCV)
14. Tachometric generator (motor)
15. Stator (motor)
16. Three-phase motor (induction)
17. Interference filter
18. Instantaneous door interlock
19. Traditional door interlock
20. Washing heating element (with thermal fuses)
21. Main circuit board
DOOR_TY Door interlock Triac
DRAIN_TY Drain pump Triac
REC_TY Triac circulation pump
K1 Heating element relay
ON/OFF Main switch (programme selector)
PWELW_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
BEL_TY Bleach solenoid Triac
