19
TECHNICAL SPECIFICATIONS
MODEL FDB1250RE FDB1050RE
ELECTRICAL
SERVICE DATA SHEET 154547801 154547901
Voltage 120VAC 120VAC
Cycles 60 Hertz 60 Hertz
Circuit Rating (Amps) 15 /20 15 /20
Motor (HP)
Motor (Amps) 0.6 0.6
Heater (Watts) 900 900
Total Amps 10.0 10.0
Temp Assure 140°F ±5°F 140°F ±5°F
Temp Boost 145°F ±5°F 145°F ±5°F
Sanitize 155°F ±5°F
Hi-Limit Thermostat 200°F 200°F
COMPONENT RESISTANCE (ohms)
Heater Element 9.28 9.28
Pump motor N/A N/A
Vent Actuator N/A N/A
Dispenser 1928 1928
Drain Motor 28 28
Water Valve Solenoid 699 699
WATER SUPPLY
Minimum Incoming Water
Temperature
120°F 120°F
Pressure (min/max
- psi)
20 / 120 20 / 120
Connection
(NPT)
3/8" 3/8"
Normal Cycle Water
Consumption (gal)
4.9 - 9.7 4.9 - 9.7
Water Valve Flow
Rate (GPM)
0.83 0.83
Water Recirculation
Rate (GPM)
approx.12 approx.12
Water Fill Time
(Seconds)
87 87
PRECISION SELECT MODEL
