INSTALLATION INSTRUCTIONS | SMART LINE BOILING PAN
EN | 10-2018 DOC N° ST0 9183-02 29
12.6.3 Installation of boiling pans with 600mm tilting height
combined with boiling pans with 400mm tilting height
PNC range tilting height 600mm:
232218 - 232245 and 232149
PNC range tilting height 400mm:
232106 - 232164
232172 - 232185
232190 - 232217
NOTE
Please follow these instructions
Boiling pans with 600mm tilting height can only be to the left of a boiling pan with 400mm tilting
height.
Boiling pan with the option ice water cooling (SV6I and SP6I) can only stand on the far left in a
multi-stand.
Check the distance to the wall behind the pan.
Order a new cover plate for the boiling pan with 600mm tilting height when having a boiling pan
with 400mm tilting height on the right.
- PNC 928151 (50L, 80L and 100L)
- PNC 928152 (150L, 200L, 300L)
Old pans refers to pans with product numbers in the following ranges:
976646xxxx to 976682xxxx
Need even an adapter: 9F92804900
See even installation instructions: ST0 91 60-xx.
