37
Sensors and overheating thermostats
Service
manual
1
Inlet air - Overheating thermostat
Function
The inlet overheating thermostat opens in the event of overheating, and shuts off the dryer.
The thermostat has to be reset manually.
Resetting
Electric heated dryer, fig. 1 and fig. 2.
The overheating thermostat on the standard is located in the bottom on the dryer (A), fig. 1.
On the condense it is located on the rear side of the back plate (B), fig. 2.
In order to reset the thermostat, shut off power and remove the back plate, see the section
"Disassembling the dryer" and press the reset button A on the thermostat, or just press the
button B on the back plate.
It is not necessary to disassemble the tumbler.
Error code
The following error code is related to this section.
E08
See Service Manual for Compass Control for more information.
A
B
2
Standard Condense
