Technical data
Service
manual
8
Technical data - type T4130/T4130C
Heating T4130 T4130C
Drum volume: 130 litres 130 litres
Weight net: 54 kg 57 kg
Drum: Diameter 575 mm 575 mm
Depth 500 mm 500 mm
Revolutions per minute 53 rpm 53 rpm
Capacity: Factor 1:25 5.2 kg 5.2 kg
Factor 1:33 3.9 kg 3.9 kg
Heat effect: Electric heating: 5.1/3.2 kW 3.0 kW
Air consumption: Heat effect 5.1 kW 210 m
3
/h -
Heat effect 3.1 kW 170 m
3
/h
Piping: Evacuation Ø 100 -
Pressure drop:
Evacuation max.
5.1 kW 80 Pa
3.1 kW 140 Pa
Sound power level: L
w
<70 dB (A) <70 dB (A)
