39
Sensors and overheating thermostats
Service
manual
1
Outlet air - Overheating thermostat
Function
The outlet air overheating thermostat is located in the outlet air flow.
The overheating thermostat opens in event of overheating.
The thermostat opens automatically and has to be reset manually.
Resetting
Electric heated dryer, fig. 1.
The overheating thermostat on the standard dryer is located behind the back plate of
the dryer at the bottom and on the right side of the dryer (A). On the condense dryer it is
located on the flange at the rear side of the door opening (B).
In order to reset the thermostat, shut of power and remove the back plate, see the
section "Disassembling the dryer" and press the reset button A or unscrew the two
screws on the flange and press the reset buttom B.
It is not necessary to disassemble the tumbler.
Error code
The following error code is related to this section.
E08
See Service Manual for Compass Control for more information.
Standard Condense
A
B
